30x60mm Aluminum ROPP Caps for Wine Glass Bottles
30x60mm ROPP Aluminum Cap (Roll-On Pilfer-Proof Aluminum Caps) is a high-quality, high-security packaging and sealing solution designed for applications with strict requirements for sealing, tamper resistance, and aesthetics.
The 30x60mm Aluminum ROPP Caps for wine glass bottles - tamper-proof, sealed, and customizable for branding. These caps are made from recyclable aluminum, ensuring freshness, meeting food-grade standards, and seamlessly integrating with automatic bottling lines.
The 30x60mm Aluminum ROPP (Roll-On Pilfer-Proof) Caps are designed for glass wine bottles, combining practicality and aesthetics. These caps are made from high-quality aluminum, ensuring a secure seal and tamper-proof closure, making them an ideal choice for preserving wine quality and freshness. The size (30mm diameter x 60mm height) fits standard and custom wine bottle neck finishes, offering versatility for bottling lines.
The 30x60mm aluminum ROPP wine glass bottle cap is a sealing accessory specifically designed for wine packaging. The 30x60mm Aluminum ROPP Cap provides an airtight barrier to prevent wine oxidation, which is crucial for preserving the aroma, flavor, and carbonation of sparkling wines.
The 30x60mm Aluminum ROPP Cap is a premium closure solution suitable for still wines, sparkling wines, spirits, and specialty beverages. They combine sealing preservation, tamper-evidence, easy drinking, and rich brand promotion functions, while also enabling efficient mass bottling and being fully recyclable.
-
Tamper-Proof:
Ensures product integrity and consumer trust.
-
Preservation:
Sealing minimizes oxygen exposure, extending shelf life.
-
User-Friendly:
No opener needed; simple twist-off design.
-
Precision Manufacturing:
Produced using advanced technology and precision molds to ensure dimensional accuracy and product consistency.
-
High Security:
Tamper-evident design ensures the product cannot be resealed once opened, providing clear indication of first use.
-
Customization Capability:
Supports a variety of surface treatments and printing processes to help brands create distinctive packaging images.
-
Eco-Friendly & Sustainable:
Made from recyclable aluminum, meeting environmental standards and supporting sustainable development.
-
Quality Assurance:
Certified by multiple international standards with strict quality control systems to ensure product stability.
HC Aluminum can manufacture caps according to your requirements or drawings. On the top, we can provide offset printing, embossing, UV printing, hot stamping, and silk screen printing. On the sides, we can offer four-color printing, embossing, hot stamping, and silk screen printing. If you have any questions, feel free to contact us, and we will provide the best service!
30x60mm Aluminum ROPP Caps Technical Specifications
30x60mm Aluminum ROPP Caps Product Details
The structural design of the 30x60mm ROPP aluminum cap is carefully optimized to perfectly fit standard bottle neck sizes:
Parameter | Value | Description |
Outer Diameter | 30mm | Precisely matches standard bottle neck size |
Height | 60mm | Provides sufficient thread length and space for tamper-evident ring design |
Thread Specification | Standard Metric Thread | Ensures tight fit with bottle neck |
Liner Diameter | 28.5-29.5mm | Varies depending on liner material |
30x60mm Aluminum ROPP Caps Technical Parameters
Item name | Aluminum caps |
Size | According to the customer's requirement |
Weight | 5g |
Color | According to the customer's requirement |
Material | Aluminum |
Decoration | Top: lithographic printing / embossing / UV printing / hot foil / silk screen print Side: embossing / hot foil / silk screen printing |
MOQ | 50000pcs |
Packing Method |
Carton ( nested packing ) 30*35*35 cmm 1570pcs per carton According to the customer's requirement |
Delivery Term | 2-4 weeks |
Supply Ability | 100000 pcs per day |
Payment Term | T/T- L/C- Western Union |
Samples Offer | Yes |
Samples Arrangement | Once confirmed, the samples will send to you within one week. |
30x60mm Aluminum ROPP Caps Structure and Materials
The aluminum cap is manufactured using the ROPP (Roll-On Pilfer-Proof) tamper-evident rolling process, which involves mechanical rolling to tightly engage with the bottle neck thread, forming an irreversible tamper-resistant structure.
Made from 8011-H14 or 3003-H16 aluminum alloy, with a thickness ranging from 0.20mm to 0.23mm, it combines ductility and strength to meet the requirements of automated production lines.
- Material: 8011 aluminum alloy (thickness: 0.23mm ± 0.015mm), lightweight and durable (4-5g per cap).
- Tamper-evident mechanism: Integrated tear-off strip, easy to open and provides tamper-evident functionality.
- Optional liners: Sarantin, Saranex, or PE liners effectively block oxygen and maintain freshness.
30x60mm Aluminum ROPP Caps Liner Materials and Performance Options
HC Aluminum offers a variety of liner material options to meet the needs of different products and applications:
-
PE Liner:
Economical, suitable for general food and beverages, provides good initial sealing.
-
EPE Liner:
Excellent elasticity and sealing performance, suitable for products with high sealing requirements.
-
Tin-Saran Liner:
Good chemical resistance and heat-sealing performance, suitable for alcoholic beverages.
-
Saranex Liner:
High barrier material, effectively prevents liquid evaporation and moisture intrusion, suitable for premium liquors and pharmaceuticals.
30x60mm Aluminum ROPP Cap Decoration Options
Lithographic printing or UV printing
Embossing, hot stamping, roll coating, capable of achieving metallic or silk-like effects
Optional surface finishes: gloss, matte, metallic texture, and tactile patterns to enhance grip or brand recognition
Decoration Techniques
Area | Options |
Top | Lithographic printing, UV printing, embossing, hot foil stamping, silk screen. |
Side | 4-color offset printing, hot foil, silk screen. |
Aesthetics and Brand Image
- Custom Colors: Wide variety—including gold, silver, black, vivid solid tones, and metallic pastels
- Logos & Patterns: Customizable through printing, embossing, or hot stamping; fully supports personalized branding
30x60mm Aluminum ROPP Caps Dimensional Accuracy and Manufacturing Tolerances
HC Aluminum strictly controls product dimensional accuracy to ensure every 30x60mm ROPP aluminum cap meets high-quality standards:
-
Outer Diameter Tolerance:
±0.2mm, ensuring perfect fit with the bottle neck.
-
Height Tolerance:
±0.3mm, ensuring consistency in appearance and functionality.
-
Thread Mid-Diameter Tolerance:
±0.1mm, ensuring smooth capping and tight sealing.
-
Wall Thickness Tolerance:
±0.015mm, ensuring consistency in product strength and weight.
-
Concentricity:
≤0.1mm, ensuring uniform force during capping to avoid skewing.
30x60mm Aluminum ROPP Caps Bottle Neck Matching and Compatibility
The 30x60mm ROPP aluminum cap is designed to be compatible with various bottle neck types and sizes, offering broad applicability:
- Standard 30mm threaded bottle neck, suitable for most glass and plastic bottles.
- Compatible with bottle neck heights ranging from 55mm to 65mm.
- Suitable for flat and slightly tapered bottle neck designs.
30x60mm Aluminum ROPP Cap Features
- Material: Lightweight, corrosion-resistant aluminum, optional coating to enhance durability and aesthetics.
- ROPP Mechanism: The cap is rolled onto the bottle neck by a capping machine, forming a tight thread for sealing.
- Tamper-Evident Band: The tamper-evident band detaches upon opening, providing visible evidence of tampering for consumer safety.
- Liner Options: Food-safe liners (e.g., plastic seal) are available to enhance oxygen barrier performance, which is critical for wine preservation.
- Custom Designs: Embossing/printing on the surface for branding, with color, logos, and finishes available.
30x60mm Aluminum ROPP Cap Applications
Application | Detailed Description |
Used for still wine in glass bottles to ensure freshness and prevent oxidation | The 30x60mm aluminum ROPP (Roll-On Pilfer-Proof) cap is widely used for still wine packaging. Its tight spiral sealing structure effectively prevents oxygen from entering, ensuring that the wine's flavor and quality are not compromised. The aluminum material has excellent sealing properties, preventing contamination from external factors and reducing oxidation that could lead to quality deterioration, thus maintaining the best condition of the wine during storage and transportation. |
Suitable for premium, organic, or bulk wine requiring reliable, recyclable sealing | The 30x60mm aluminum ROPP cap is an ideal choice for premium, organic, and bulk wine producers due to its security and recyclability. Its tamper-evident design provides consumers with added security, ensuring the cap has not been tampered with. |
Compatible with automatic bottling lines for efficient high-volume production | The 30x60mm aluminum ROPP cap is designed specifically for modern automated production systems and seamlessly integrates with high-speed bottling lines. Its standardized size and thread structure allow it to fit various bottle necks, improving production efficiency and reducing sealing errors. |
30x60mm Aluminum ROPP Caps Production Process
Raw Material Preparation and Treatment
High-quality 8011 aluminum alloy material is carefully selected and subjected to surface cleaning, annealing, and leveling treatments to ensure the quality of subsequent processing.
Forming and Processing Technology
High-precision stamping molds and precision thread processing equipment are used to ensure dimensional accuracy and surface quality of the product.
Surface Treatment and Printing Process
Provides coating treatment, electrochemical treatment, anodizing, and various printing processes to meet different customer requirements.
Liner Installation and Quality Inspection
Automated liner installation equipment is used, and quality is ensured through visual inspection, dimensional measurement, and sealing performance testing.
Packing and Storage & Transportation
Nesting packaging is used to ensure that products are not affected by the environment during transportation and are stored in a dry and well-ventilated environment.
30x60mm Aluminum ROPP Cap FAQs
How is the sealing performance of the 30x60mm ROPP aluminum cap?
HC Aluminum’s 30x60mm ROPP aluminum caps use specially designed liners and precisely machined threads to provide excellent sealing performance. Tests show no leakage within a pressure range of -0.08MPa to +0.3MPa, ensuring sealing integrity during normal storage and transportation. The choice of liner material also affects sealing performance. We offer a variety of liner materials, including PE, EPE, Tin-Saran, and Saranex, to meet different sealing requirements.
Is the opening torque of the aluminum cap moderate, ensuring both tamper resistance and ease of opening?
Yes. Our 30x60mm ROPP aluminum caps feature a specially designed tamper-evident ring structure, with an opening torque (breakaway torque) controlled between 1.5-4.0N·m. This ensures good tamper resistance while remaining easy for consumers to open. The connection points of the tamper-evident ring are reasonably designed to produce a noticeable breaking sound and visual indicator when opened. The aluminum cap can also be re-tightened after opening.
Can the aluminum cap withstand high-temperature sterilization processes?
Yes. Our 30x60mm ROPP aluminum caps can withstand conventional high-temperature sterilization processes, including moist heat sterilization (121℃ for 30 minutes) and dry heat sterilization (180℃ for 1 hour). After high-temperature sterilization, the aluminum cap shows no significant deformation or damage, and the sealing performance remains good. For applications requiring high-temperature sterilization, it is recommended to select high-temperature-resistant liner materials, such as Teflon or specially treated PE materials.
What types of bottle necks are suitable for the 30x60mm ROPP aluminum cap?
Our 30x60mm ROPP aluminum caps are mainly suitable for standard threaded bottle necks with a 30mm outer diameter, including both glass and plastic bottles. The applicable bottle neck types include: standard 30mm threaded necks, flat and slightly tapered neck designs. Tests show that our 30x60mm ROPP aluminum caps are compatible with over 95% of standard 30mm bottle necks on the market. For specially designed bottle necks, it is recommended to provide samples for compatibility testing.
Comparison: Screw Caps vs Corks
- Oxidation Control: Screw caps outperform natural corks; reduce risk of cork taint.
- Resealability: Easier to reseal than cork, more convenient for consumers.
More Information about 30x60mm Aluminum ROPP Cap
- Size: 30mm nominal diameter (fits bottle neck) x 60mm total height (including cap and tamper-evident band).
- Material Thickness: Sturdy and durable structure; complies with FDA/EU food contact regulations.
- Torque Requirements: Optimized to ensure safe application without damaging the bottle neck.
Compliance and Safety
- Complies with global food-grade standards (FDA, EU 10/2011).
- Certified for direct contact with alcoholic beverages for the liner.
Additional Options
- Induction seal liners to enhance leak resistance.
- Custom embossing/debossing to create a high-quality brand image.
